Circuit Breaker CJX2-2510.Permanent Electromagnetic Switch 3 Phase 3 Pole Silver 24-380V 50/60Hz DIN Rail Relay AC.Protect

Description

VUBBJCRS
Circuit Breaker
Circuit Breakers

Specifications:
The coil voltage is not the main voltage and the nameplate marks the coil pickup voltage.
For example: the voltage of the coil is 24V, then A1.A2 can not be connected to voltage other than 24V.
Wrong connection will cause the coil not to work or the coil will burn.
Type 1 is 24V, Type 2 is 36V, Type 3 is 48V, Type 4 is 110V, Type 5 is 220V, Type 6 is 380V.
Item name: AC.Protect
Model: CJX2-2510.Usually open
Rated current: 25A
Number of poles: 3
Auxiliary type: silver
Coil voltage: 24-380V
Coil Frequency: 50/60Hz
Coil power supply: AC
Rated voltage: 690V
Isolation voltage: 69 0V AC.
Heater current: 40A
Working altitude: 2000m
Working environment temperature: -5 to 40 degrees Celsius
Material: ABS
Arc extinguishing medium: air type
Number of main rods: three poles
Mechanical life: 3600 (million times)
Electrical life: 1200 (million times)
Scope of application: security control
Application scenario: terminal power distribution
Main circuit: AC.Protect
Number of normally open main contacts: 3
Number of normally closed auxiliary contacts: 0
Number of normally closed main contacts: 0
Number of normally open auxiliary contacts: 1
Size: 9cm x 10.5cm x 6cm / 3.54" x 4.13" x 2.36" (Approx.)
Remarks:
Due to the light and screen setting difference, the item's color maybe slightly different from the pictures.
allow slight dimension difference due to different manual measurement.
Package includes:
1 xAC.Protect
