Feelworld 21.5 inch 3G-SDI 4K HDMI Broadcast Studio Monitor IPS Full HD 1920x1080 FS215-S4K

Description

• The FeelWorld 21.5" Full HD IPS Broadcast Studio Monitor features a 1920 x 1080 resolution and supports up to DCI 4K HDMI signal input and loop-through output. It has a robust aluminum housing that provides durability in all scenarios while also allowing increased heat dissipation.
• The monitor offers UMD (Under Monitor Display) and Text-Tally Display, with UMD supported via RS-485 input and loop-through out. It has a 178 viewing angle and offers multiple assist features, including peaking and pixel-to-pixel.
• FS215-S4K supports UMD and Text-Tally display of TSL 3.1/4.0 protocol, with 0-126 TSL address selection, and Max 16 letters displayed. The UMD inputs via RS485 port and outputs via RS485 port.
• The monitor comes with 3G/HD/SD-SDI, HDMI, Audio, Video, RS485, DVI-I inputs. Multiple input formats to meet all HD, SD, analogue video signal input and display demand Professional functions set.
• The FS215-S4K can be powered in two ways: with an DC adapter or lithium batteries. The FS215-S4K has a flexible battery system that supports V battery plate (standard), Anton Bauer battery plate of your choice.

1. Wide view angle IPS Screen, Full HD 1920x1080, bright, colorful display 2. HDMI, 3G-SDI, Video, Audio(L/R), RS485, DVI inputs and HDMI, 3G-SDI, Video, RS485 loop-through outputs 3. Special Features: * UMD and Text-Tally Display (TSL 3.1/4.0 Protocol)
* Peaking Focus Assist (Red highlight over parts of the monochrome image in focus)
* Check Field (Red, Green, Blue, Mono)
* Camera Mode
* Pixel to Pixel
* Center Marker
* Safe Marker (80%, 85%, 90%, 93%, 96%, 2.35:1) * Image Flip (Horizontal, Vertical, Hor&Ver)
* Image Freeze
* Zoom All
* U/D & L/R Zoom
4. Monitoring via front panel 3.5mm stereo headphone jack and built-in speaker
5. Built-in LED tally indicators (Red, Green, Yellow) optional
6. Power using included 12-volt supply or use standard 4-pin XLR

Model FS215-S4K
Screen Size 21.5" IPS
Color Depth 16.7M
Resolution 19201080 pixels
Dot pitch 248.25x248.25 um
Aspect Ratio 16:9
Brightness 250cd/m
Contrast Ratio 3000:1
Backlight LED
Viewing Angle 89/89(L/R) 89/89(U/D)

Input
1 X BNC 3G-SDI
1 X HDMI HDMI
1 X Video Video
2 X RCA Audio(L/R)
1 X DVI-I DVI-I
1 X RS485 RS485

Output
1 X BNC 3G-SDI
1 X HDMI HDMI
1 X Video Video
1 X RS485 RS485

Audio
Audio Stereo Headphone, Speaker

SDI Support Format
480i/576i
720p(60/59.94/50/30/29/25/24/23.98)
1080i(60/59.94/50)
1080p(60/59.94/50/30/29.97/25/24/24sF/23.98/ 23.98sF)

HDMI Support Format
480i/576i/480p/576p
1080i (60/59.94/50)
720p (60/59.94/50/30/29/25/24/23.98)
1080p (60/59.94/50/30/29.97/25/24/24sF/23.98/ 23.98sF)
4K UHD 38402160p (30/29.97/25/24/23.98Hz), 40962160p (24Hz)

General
Input Voltage DC9-24V
Power Consumption 18W
Working Temperature -10C~50C
Storage Temperature -20C~60C
Unit Size: 511.56Lx355.6Hx36.33D (mm) (W/O stand feet)
Unit Weight: 4.4kg
