FEELWORLD ATEM156 15.6 Inch Live Streaming Broadcast Director Monitor for ATEM Mini Video Switcher Mixer Pro Studio Television Production with 4 HDMI Input Output Quad Split Display

Description

• 4 X 4K HDMI Input and OutputATEM156 has 4 X 4K HDMI input and output, which can connect up to 4 cameras, game consoles, computers and other equipment. At the same time, it can also loop out 4 HDMI signals to other devices, such as ATEM Mini or ATEM Mini Pro. This is very useful for studio and live multi-camera shooting.
• Improve the Shooting EfficiencyFEELWORLD ATEM156 Equipped with four 4K HDMI inputs, it supports quad view, dual view, and single view monitoring functions, allowing you to get perfect multi-camera monitoring in any location! It contains focus-checking functions, such as Peaking Focus, False Color, and Pixel to Pixel, to assist in getting sharp images.
• High resolutionThe FEELWORLD ATEM156 equipped with a 15.6 inch IPS LCD panel, allows you to have 1920 x 1080 resolution for each pixel in the HDMI input under the PIS LCD panel, with a contrast ratio of 800:1 and a 170 wide viewing angle in the vertical direction.
• Easy Button OperationIt is equipped with a simple control panel, you can customize the shortcut key functions and quickly call them out. You can use the 12V DC power input and V- mount battery plate to power monitor.
• Live Production Broadcast MonitorATEM156 is an affordable way to create incredible programs immediately from live events! It is very suitable for the use of broadcasters, live sports, concerts, lectures and seminars, eSports and gaming competitions, web broadcasters, and other scenarios. It can meet your indoor and outdoor multi-camera monitoring needs.

Model: ATEM156
Screen Size: 15.6" IPS
Color Depth: 16.7M colors (8-bits)
Resolution: 19201080 pixels
Pixel Pitch: 0.17925 (H) X 0.17925 (V) mm
Aspect Ratio: 16:9
Brightness: 250cd/m
Contrast Ratio: 800:1
Backlight: LED
Viewing Angle: 85/85(L/R) 85/85(U/D)

Input
4 X HDMI HDMI (Support 4K 30Hz)

Output
4 X HDMI HDMI (Support 4K 30Hz)

Audio
Audio Out 3.5mm Stereo Headphone, Speaker

HDMI Support Format
480i/576i/480p/576p
720p (60/59.94/50/30/29.97/25/24/23.98)
1080i (60/59.94/50)
1080p (60/59.94/50/30/29.97/25/24/23.98)
38402160p (30/25/24), 40962160p (24)
General
Input Voltage: DC1224V
Power Consumption: 12W
Working Temperature: -10C~50C
Storage Temperature: -20C~60C
Unit Size (mm): 372L262H28.4D (mm) (Without Bracket)
Unit Weight: 1.57kg (Without Bracket)

Advanced Features
* Quad Split Display (1P, 2P LR, 2P TB, 2P PIP, 4P)
* Peaking Focus Assist
* False Color
* Anamorphic (x1.33, x1.5, x1.8, x2.0)
* Display Rotate (0, 90, 180, 270, H Mirror, V Mirror)
* Check Field (Red, Green, Blue, Mono)
* Image Freeze
* Zoom
* Pixel to Pixel
* Center Marker
* Safety Marker (80%, 85%, 90%, 93%, 96%, 4:3, 2.39:1, 2.35:1, 1.85:1)
* Line Color (Red, Green, Blue, White
* Color Temperature Adjustment
