LILLIPUT 17.3" Q17 FHD PRO SDI Filmmaking Monitor 3D Lut HDR Waveform/Vector/Histogram/4 Bar Display/Audio Vector/Level Meter with Gold mount and 19" rack mount ears by VIVITEQ

Description

• LILLIPUT 17.3" Q17 FHD PRO SDI Filmmaking Monitor 3D Lut HDR Waveform/Vector/Histogram/4 Bar Display/Audio Vector/Level Meter
• What's in the package: 1.Gimbal Bracket 2.Acylic Screen Protector 3.Suitecase(Black) 4. USB Drive Disk 5. Mount plate Bracket 6. Gold mount plate 7.15V DC adapter 8. Desktop Bracket 9.19" rackmount ears Bracket

LILLIPUT 17.3" Q17 FHD PRO SDI Filmmaking Monitor 3D Lut HDR Waveform/Vector/Histogram/4 Bar Display/Audio Vector/Level Meter
Main Features
Support standard 12G-SDI input interface (x2), 3G-SDI input interface (x2), and support Single-Link, Dual-Link and Quad-Link signals.
Support HDMI 2.0/1.4 inputs and loop outputs.
support SFP optical Connector input, optical module for optional.
Loop output signals support up to 3840x2160 23.98/24/25/29.97/30/50/59.94/60p and 4096x2160 23.98/24/25/29.97/30/47.95/48/50/59.94/60p.
Monitor control via LAN, GPI, RS422.
Customized Menu Knob.
Support customized various waveform mode: Waveform/Vector/Histogram/4 Bar Display/Audio Vector/Level Meter.
HDR (High Dynamic Range) display supporting ST 2084 and Hybrid Log Gamma.
Gamma selection: 1.8-2.8.
Custom 3D LUT file load through USB.
Wide color space supporting SMPTE-C, Rec709, EBU, and Native. Color Space/ HDR/Gamma /Camera Log comparison with original (side by side). Color Temperature: 3200K/5500K/6500K/7500K/9300K/User.
False Color: Default/Spectrum/ARRI/RED.
Aspect Marker (16:9/1.85:1/2.35:1/4:3/2.0X/2.0X MAG/Grid/User).
Aspect (Full/16:9/1.85:1/2.35:1/4:3/3:2/2.0X/2.0X MAG).
Audio: supporting Audio Phase and Level Meter, HDMI supporting 8 channels, and SDI supporting 16 channels.
Time Code: LTC/VITC.
UMD display : White/Red/Green/Blue/Yellow/Cyan/Magenta text color for optional. Color Bar Mode: Rec601/Rec709/BT2020. Check Field: Red/Green/Blue/Mono. Zoom at any position and at a different scales. Peaking (Red/Green/Blue/White/Black). Tally (Red/Green/Yellow). Product Parameters Panel Size 17.3" Resolution 19201080 The luminance of white 300 cd/M2 Contrast Ratio 1200:1. Viewing Angle 170 /170 Deg (H/V) Input Connector 12G-SDI*2, 3G-SDI*2, HDMI 2.0, GPI, RS422, LAN, USB Output Connector 12G-SDI*2, 3G-SDI*2, HDMI 2.0, RS422, Earphone jack Power RequirementsDC 12-24V Power Consumpt
