LYAART SFP-25GBX-U-40 Compatible 25GBASE SFP28 1270nm-TX/1310nm-RX 40km DOM Simplex LC SMF Optical Transceiver Module (Color : 1330nmTx 1270nmRx)

Description

• Network-transceivers

network-transceivers
NOTE: This Product Requires a Pair to Use
SFP-25GBX-U-40 Compatible 25GBASE-BX40-U SFP28 Optical Transceiver Module for Data Center and Telecom (SMF, 1270nm-TX/1310nm-RX, 40km, LC, DOM)
SFP-25GBX-U-40 compatible SFP28 transceiver provides 25GBase-BX throughput up to 40km over single mode fiber (SMF) using a wavelength of 1270nm-TX/1310nm-RX via an LC simplex connector. This bidirectional unit must be used with another transceiver or network appliance of complimenting wavelengths. It provides 25GBASE Ethernet connectivity option for 25G Ethernet, telecom and data center. It is fully compliant with the SFP28 MSA, CPRI and eCPRI standard.
Specifications
AO-SFP-25GBX-U-40
Form Factor
SFP28
Max Data Rate
25.78Gbps
Wavelength
1270nm-TX/1310nm-RX
Max Cable Distance
40km
Connector
Simplex LC
Media
SMF
Transmitter Type
DFB BiDi
Receiver Type
APD
TX Power
0~6dBm
Receiver Sensitivity
<;-18dBm
Powerbudget
18dB
Receiver Overload
2dBm
Power Consumption
1.2W
Extinction Ratio
3.5dB
CDR
TX and RX
FEC Function
Not Supported @ 30km
Commercial Temperature Range
0 to 70C (32 to 158F)
Protocols
MSA Compliant, CPRI
