TE Connectivity W31-X2M1G-5 Circuit Breaker Therm Togl 5A Panel 1 Pole Vol-Rtg 240VAC/50VDC W31-X2M1G-5

Description

• Product Overview The W31-X2M1G-5 is a 5A toggle/push/pull actuator Thermal Circuit Breaker, calibration will continuously carry 100% of rating, may trip between 101% and 134% of rating at 25C, must
• Ten times rated current is resettable overload capacity, over 1500V RMS dielectric strength, endurance cycling is more than 6000 cycles at 100% of rating or 10000 mechanical cycles
• Threaded bushing, 15/32-inch diameter with or without anti-rotation flats panel mounting, 250VAC/50VDC voltage rating
• Screw terminals situated 90 to each other with #8-32 screws and washers installed and also two hex nuts or lock washer installed
• Cannot be reset against overload Visible trip indicator band Screw termination Trip-free operation Single pole Silver color metal toggle round with amp rate marking on end toggle Applications

TE Connectivity W31-X2M1G-5 Circuit Breaker Therm Togl 5A Panel 1 Pole Vol-Rtg 240VAC/50VDC W31-X2M1G-5
